Mobile Workshop Truck
Start with the repairs the workshop truck will carry out in the field. Allow for tools, a workbench, air, welding and power, with enough storage, payload and access for servicing.
- Workshop Length
- 3–6 m
- Workshop Equipment
- Tool cabinet / bench / compressor / welder
- Tool Storage Capacity
- 10–30 Cabinets / Drawers
Front three-quarter view of the mobile workshop truck, showing the blue box body and large side access doors (1 of 6)Technical specifications
| Item | Value |
|---|---|
| Body and layout | |
| Workshop Length | 3–6 m |
| Equipment and published ratings | |
| Workshop Equipment | Tool cabinet / bench / compressor / welder |
| Tool Storage Capacity | 10–30 Cabinets / Drawers |
| Generator Power | 5–30 kW |
| Air Compressor Capacity | 0.3–1.0 m³/min |
| Power Supply | Generator / shore power / combined |
Published configuration range · Data sheet v1.1 · Source checked · Supporting documents
Repairs, tools and workshop space
Typical work
- Remote fleet repair
- Disaster-site maintenance
- Utility and infrastructure support
Configuration details
- Repair tasks and tool schedule
- Workshop length and access
- Power, air and welding demand
- Storage, payload and service access
- Hydraulic duty
- State flow at total dynamic head, intake, solids, hose route and outfall.
- Power and runtime
- List connected loads, starting sequence, runtime, cable route and protection.
- Field service
- Define repairs, crew, tools, consumables, storage and service interval.
Acceptance requirements
- Reconcile installed equipment, rated interfaces, cables, hoses, controls and loose items to the approved schedule.
- Witness the specified duty point or load schedule with identified instruments and retained results.
- Record completed-vehicle mass, axle loads, drawings, manuals, safeguards and exceptions.
Build and inspection
Final dimensions, installed equipment, route suitability and acceptance records are confirmed for the selected project.
Equipping the mobile workshop
Which repairs can the workshop support?
Define the repairs and identify each required system in the quotation. Welding, lifting and diagnostics are not automatically included.
Can the tools run at the same time?
Size the power or air supply for the tools that will run together. A tool inventory alone does not establish simultaneous operation.
What needs its own commissioning check?
Each specified specialist system does. A generator test does not commission a welder, compressor or lifting attachment.
Do spare parts count towards payload?
Yes. Include stocked parts along with tools and machines when defining the completed workshop load. Use a numbered handover inventory for loose tools and supplies, tied to the agreed repair scope.
Which contents need separate transport arrangements?
Identify cylinders, oils and batteries and agree their treatment with the carrier. These contents need to be stated explicitly, not left inside a general workshop description.
Specify your Mobile Workshop Truck
Share the operating duty, destination and equipment requirements.
